"CYSALO 13 deep "
Attention pleasure tourers! The "CYSALO 13" not only offers the proven, low and wide entry, which makes getting on the bike particularly comfortable. It is also equipped with the slightly more torquey Bosch "Active Line Plus" drive. What's more, the "PowerPack 500" Battery integrated in the Carrier does not need to be recharged after every short trip. Conversely, this also means that Dropouts can also be a little longer.
The low-maintenance 7-speed "Nexus" gear hub rounds off the drive package. It has a backpedal function. The "CYSALO 13" is therefore equipped with three brakes. This is because the tried-and-tested hydraulic "HS11" Rim Brake from Magura brakes on both rims.
Comfort - the keyword that characterizes the VICTORIA brand - is definitely not neglected on the "CYSALO". Thanks to the Suspension Fork, suspended Seatposts, rearward offset Comfort Handlebars and ergonomic Grips, it relieves as much strain as possible. The pedelec is road-ready thanks to the sturdy aluminum Fenders, which keep out dirt and rainwater, as well as the Contec lights. With a solid 30 lux, the Front Light illuminates the way home.
The low-maintenance 7-speed "Nexus" gear hub rounds off the drive package. It has a backpedal function. The "CYSALO 13" is therefore equipped with three brakes. This is because the tried-and-tested hydraulic "HS11" Rim Brake from Magura brakes on both rims.
Comfort - the keyword that characterizes the VICTORIA brand - is definitely not neglected on the "CYSALO". Thanks to the Suspension Fork, suspended Seatposts, rearward offset Comfort Handlebars and ergonomic Grips, it relieves as much strain as possible. The pedelec is road-ready thanks to the sturdy aluminum Fenders, which keep out dirt and rainwater, as well as the Contec lights. With a solid 30 lux, the Front Light illuminates the way home.
Specifications "Victoria CYSALO 13 deep (2023)"
| Frame: | Alu 6061 |
| Fork: | SUNTOUR "SF14 CR-85 E25", einstellbar, 50mm Travel, Pivot |
| Crank arm: | Miranda "PSI" |
| Chain ring / belt ring: | MIRANDA, 38T |
| Bottom Bracket: | BOSCH |
| Brakes: | MAGURA "HS11" |
| Brake lever: | MAGURA "HS11" |
| Shifting lever: | SHIMANO "Nexus", 7-Gg. |
| Cassette / belt sprocket: | SHIMANO, 20 Z. |
| Chain / belt: | KMC "Z1eHX Narrow EPT" |
| Drive unit: | BOSCH Mittelmotor Gen.3 "Active Line PLUS", 36 V, 250 W |
| Battery: | BOSCH "Powerpack 500", Lithium-Ionen mit BMS, 500 Wh |
| Charger: | BOSCH 2 Ah |
| Display: | BOSCH, "Intuvia " 4-Stufen, Remote Control, Schiebehilfe |
| Sensor: | Tretkraftmessung im Motor + Geschwindigkeitssensor |
| Rims: | MACH "840" |
| Spokes: | 2,0 mm, Niro |
| Front hub: | SHIMANO "HB-TX500", 36 L., QR |
| Rear hub: | SHIMANO "Nexus" 7-Gg. RBN |
| Front tires: | CONDURA "Dayak", 50-622, schwarz/reflex, 3mm Pannenschutzeinlage, 30 TPI |
| Rear tires: | CONDURA "Dayak", 50-622, schwarz/reflex, 3mm Pannenschutzeinlage, 30 TPI |
| Handle bar: | CONTEC "Mito 90", Breite 620 mm, Rise 28 mm, 37° Backsweep |
| Stem: | CONTEC "Lida Hybrid", 31,8 mm, 90mm, Schaftvorbau, verstellbar, schwarz |
| Grips: | CONTEC "Tour Wing Eco" |
| Saddle: | SELLE ROYAL "ESSENZA- PLUS", Relaxed Elastomer |
| Seat post: | CONTEC "Kano", 27,2 mm, 350 mm, schwarz |
| Chain guard: | HESLING "Move" Bosch Gen.3 |
| Mud Guards: | CURANA "Apollo", 60mm, schwarz |
| Carrier: | MIK-ALU-GEPÄCKTRÄGER "TA7611A" MIK-System |
| Front light: | CONTEC "Dlux 30 E+" 30 Lux |
| Tail light: | CONTEC „TL-335 E+" |
| Frame Lock: | CONTEC "Powerloc M AZ" |
| Kickstand: | URSUS "King2", Hinterbau, 18 mm, verstellbar |
| Pedals: | UNION "SP-827", Antislip |
Technical data
| Category: | trekking bike |
| E-bike: | yes |
| Bosch Smart System: | no |
| Drive system: | BOSCH Active Line Plus |
| Drive version: | middle motor |
| Battery capacity: | 500 Wh |
| Support: | till 25km/h |
| Sex: | ladies |
| Frame shape: | deep |
| Frame size: | S |
| Frame height: | 46 cm |
| Wheel size: | 28" |
| Shifting type: | hub gear |
| Gears: | 7-speed |
| Circuit brand: | Shimano |
| Shifting model: | Nexus |
| Brake system: | hydraulic rim brake, coaster brake |
| Travel: | 50 mm |
| Features: | suspension fork, suspensed seat post, frame lock, system carrier, chain guard, electronic sliding aid, fender |
| Zulässiges Systemgewicht: | 140 kg |
| Material: | aluminium |
| Colour: | grey |
| Colour designation: | agate grey |
| Weight: | 24,90 kg |
| EAN | 4251971112186 |
Geometry data "Victoria CYSALO 13 deep (2023)"
| Seat tube: | 460 mm |
| Toptube: | 588 mm |
| Steering tube angle: | 70° |
| Seat angle: | 72° |
| Kettenstrebe: | 495 mm |
| Steering tube: | 175 mm |
| Reach: | 365 mm |
| Stack: | 647 mm |
| Access height: | 425 mm |
| Wheel distance: | 1.126 mm |
