"Avyon 5 diamond "
The "AVYON 5" is representative of Victoria's commitment to comfort. It is the only model in the "AVYON" range with hub gears and Straps.
Comfort is also ensured by the air-sprung Suntour Fork with 100 mm travel and Thru Axles at the front and rear.
The new "eRuban" SUV all-round tires from Continental, on the other hand, provide more tires thanks to the energy-saving tread. The higher shoulder lugs provide the necessary grip on damp meadows and loose surfaces.
The smart Bosch "Performance CX" mid-motor provides support with a full 85 Nm of torque, the energy for which comes from the "PowerTube 750".
The "AVYON 5" is particularly low-maintenance because it is equipped with a Gates CDX Straps instead of a chain. The polyurethane and carbon fiber material mix makes it weather-resistant and strong. The automatic and continuously variable Enviolo internal gear hubs complete the low-maintenance equipment.
Curana Fenders, a MIK Carrier and the "bun lock" round off the features of this comfort all-rounder. Reflective Stripes on the tires and the lights ensure roadworthiness. At the front, a powerful 80 lux lights your way home. At the rear, the bike is equipped with a rear light plus stop light function for extra safety. This makes it easier for cyclists behind to react to spontaneous braking maneuvers, which are often unavoidable in city traffic.
Comfort is also ensured by the air-sprung Suntour Fork with 100 mm travel and Thru Axles at the front and rear.
The new "eRuban" SUV all-round tires from Continental, on the other hand, provide more tires thanks to the energy-saving tread. The higher shoulder lugs provide the necessary grip on damp meadows and loose surfaces.
The smart Bosch "Performance CX" mid-motor provides support with a full 85 Nm of torque, the energy for which comes from the "PowerTube 750".
The "AVYON 5" is particularly low-maintenance because it is equipped with a Gates CDX Straps instead of a chain. The polyurethane and carbon fiber material mix makes it weather-resistant and strong. The automatic and continuously variable Enviolo internal gear hubs complete the low-maintenance equipment.
Curana Fenders, a MIK Carrier and the "bun lock" round off the features of this comfort all-rounder. Reflective Stripes on the tires and the lights ensure roadworthiness. At the front, a powerful 80 lux lights your way home. At the rear, the bike is equipped with a rear light plus stop light function for extra safety. This makes it easier for cyclists behind to react to spontaneous braking maneuvers, which are often unavoidable in city traffic.
Specifications "Victoria Avyon 5 diamond (2024)"
| Frame: | Bosch-Intube-SUV-Frame, Aluminium 6061 |
| Fork: | SUNTOUR "SF21-MOBIE34 AIR", einstellbar, Lockout, 100mm |
| Crank arm: | FSA "CK-745", Gen.4 |
| Chain ring / belt ring: | GATES "CDX", 46 Z. |
| Bottom Bracket: | BOSCH |
| Brakes: | SHIMANO "BR-MT420/410" |
| Brake lever: | SHIMANO "BR-MT401" |
| Front rotor: | SHIMANO "SM-RT30", 203mm, Center-Lock |
| Rear rotor: | SHIMANO "SM-RT26", 180mm, 6-Loch |
| Shifting lever: | ENVIOLO, Drehgriff stufenlos |
| Cassette / belt sprocket: | GATES "CDX", 24 Z. |
| Chain / belt: | GATES "CDX", Belt, 122 Z. |
| Drive unit: | BOSCH "Performance CX", 36 V, 250 W |
| Battery: | BOSCH "Powertube 750", Lithium-Ionen mit BMS, 750 Wh |
| Charger: | BOSCH 4 Ah |
| Remote: | BOSCH, "BRC3600" LED Remote |
| Display: | BOSCH, "Kiox 300" 4-Stufen, Remote Control, Schiebehilfe |
| Sensor: | Tretkraftmessung im Motor + Geschwindigkeitssensor |
| Rims: | MACH 1 "MAXX" |
| Spokes: | 2,0 mm, Niro, black |
| Front hub: | SHIMANO "HB-MT400", QR 15, Disc, Center Lock |
| Rear hub: | ENVIOLO "Heavy Duty", 148mm, stufenlos |
| Front tires: | CONTINENTAL "eRuban", 27"x2,3, Reflex |
| Rear tires: | CONTINENTAL "eRuban", 27"x2,3, Reflex |
| Handle bar: | ERGOTEC "Low Riser Bar", 720 mm, Ø 31,8 mm, schwarz |
| Stem: | ERGOTEC "Sepia 50", Ø31,8 mm, verstellbar, schwarz, 90mm |
| Grips: | CONTEC "G-Link Trekking Wing short" |
| Saddle: | SELLE ROYAL "Explora" Italy, Moderate Male |
| Seat post: | ERGOTEC Patent "Viper", Ø 31,6 mm, 10mm Setback, Alu, black |
| Chain guard: | CURANA "Chainguard" |
| Mud Guards: | CURANA "Apollo", 70mm, schwarz matt, Spoiler |
| Carrier: | MIK-ALU-GEPÄCKTRÄGER "TA7652A" MIK-System |
| Front light: | CONTEC "Dlux 80 E+" 80 Lux |
| Tail light: | CONTEC „TL-335 E-Stop“, mit Stoplicht |
| Frame Lock: | CONTEC "Powerloc XL AZ" |
| Kickstand: | URSUS "King2", für Victoria Hinterbau, 40 mm, verstellbar |
| Pedals: | VP "VP-531E", Alu, |
Technical data
| Category: | SUV |
| E-bike: | yes |
| Bosch Smart System: | yes |
| Drive system: | BOSCH Performance Line CX |
| Drive version: | middle motor |
| Battery capacity: | 750 Wh |
| Support: | till 25km/h |
| Sex: | gents |
| Frame shape: | diamond |
| Frame size: | M |
| Frame height: | 53 cm |
| Wheel size: | 27,5" |
| Drive: | belt drive |
| Shifting type: | hub gear |
| Gears: | stepless |
| Circuit brand: | Enviolo |
| Shifting model: | HD |
| Brake system: | hydraulic disc brake |
| Travel: | 100 mm |
| Features: | suspension fork, system carrier, chain guard, electronic sliding aid, fender |
| Zulässiges Systemgewicht: | 140 kg |
| Material: | aluminium |
| Colour: | white |
| Colour designation: | river blue matt |
| Weight: | 30,10 kg |
| EAN | 4251971110281 |
Geometry data "Victoria Avyon 5 diamond (2024)"
| Seat tube: | 530 mm |
| Toptube: | 627 mm |
| Steering tube angle: | 69° |
| Seat angle: | 73° |
| Kettenstrebe: | 467 mm |
| Steering tube: | 160 mm |
| Reach: | 425 mm |
| Stack: | 660 mm |
| Standover height: | 833 mm |
| Wheel distance: | 1.166 mm |
