"TRESALO 15 diamond "
The Victoria TRESALO 15 hub-gear model is a reliable companion for both everyday use and touring. The Shimano “Nexus” 5-speed Hub, designed specifically for use on e-bikes, is available with either a coaster brake or a freewheel. The smart Bosch system provides more than enough support for your pedaling effort thanks to the new Performance engine and the “PowerTube 625” battery.
The “Kiox 300” color display provides useful information about your current route and remains perfectly legible even in the dark. If the available information isn’t enough, you can access additional features via the free eFlow app. When paired with other navigation apps, such as Komoot or Strava, this opens up a whole new world of riding experiences with your new bike.
We’ve designed the TRESALO models with integrated PowerTube batteries to feature a stable and stiff frame. The riding position—as you’d expect from a Victoria—is more upright and comfort-oriented than overly sporty and stretched out.
As with all new Victoria models, the battery integrated into the down tube can be removed from the top. This eliminates the need to support the bike, as is required when removing it from the bottom. However, given the large capacity and the resulting weight of the battery, we recommend charging it while it’s still in the bike, as it’s simply more convenient.
The “Kiox 300” color display provides useful information about your current route and remains perfectly legible even in the dark. If the available information isn’t enough, you can access additional features via the free eFlow app. When paired with other navigation apps, such as Komoot or Strava, this opens up a whole new world of riding experiences with your new bike.
We’ve designed the TRESALO models with integrated PowerTube batteries to feature a stable and stiff frame. The riding position—as you’d expect from a Victoria—is more upright and comfort-oriented than overly sporty and stretched out.
As with all new Victoria models, the battery integrated into the down tube can be removed from the top. This eliminates the need to support the bike, as is required when removing it from the bottom. However, given the large capacity and the resulting weight of the battery, we recommend charging it while it’s still in the bike, as it’s simply more convenient.
Specifications "Victoria TRESALO 15 diamond (2025)"
| Frame: | Bosch-Intube-Frame, Aluminium 6061 |
| Dropout: | Slider Dropout |
| Fork: | SUNTOUR "SF19-NEX E25 NLO", einstellbar, Lockout, 63mm |
| Crank arm: | Miranda "PSI" |
| Chain ring / belt ring: | MIRANDA, 38T |
| Bottom Bracket: | BOSCH |
| Brakes: | SHIMANO "BR-MT200" |
| Brake lever: | SHIMANO "BL-MT201" |
| Front rotor: | SHIMANO "SM-RT30", 180mm, Center-Lock |
| Rear rotor: | SHIMANO "SM-RT30", 160mm, Center-Lock |
| Shifting lever: | SHIMANO "Nexus", 5-Gg. |
| Cassette / belt sprocket: | SHIMANO, 27 Z. |
| Chain / belt: | KMC "Z1eHX Narrow EPT" |
| Drive unit: | BOSCH "Performance", 36 V, 250 W |
| Battery: | BOSCH "Powertube 625", Lithium-Ionen mit BMS, 625 Wh |
| Charger: | BOSCH 4 Ah |
| Display: | BOSCH, "Kiox 300" 4-Stufen, Remote Control, Schiebehilfe |
| Sensor: | Tretkraftmessung im Motor + Geschwindigkeitssensor |
| Rims: | MACH "630 KARMA Disc" |
| Spokes: | 2,0 mm, Niro |
| Front hub: | SHIMANO "HB-RM35" QR, Center Lock |
| Rear hub: | SHIMANO "Nexus" 5-Gg. LL |
| Front tires: | MAXXIS "Metropass", 50-622, Reflex |
| Rear tires: | MAXXIS "Metropass", 50-622, Reflex |
| Handle bar: | ERGOTEC "Riser Bar 50", 720 mm, Ø 31,8 mm, schwarz |
| Stem: | ERGOTEC "Sepia 50", Ø31,8 mm, verstellbar, schwarz, 90mm |
| Grips: | CONTEC "Tour Wing" |
| Saddle: | SELLE ROYAL "ESSENZA" Italy, Moderate Male |
| Seat post: | ERGOTEC Patent "SP10", gefedert, Ø 27,2 mm, Alu |
| Chain guard: | HESLING "Move" Bosch Gen.3 |
| Mud Guards: | CURANA "Apollo", 60mm, schwarz matt, Spoiler |
| Carrier: | MIK-ALU-GEPÄCKTRÄGER "TA7653A" MIK-System |
| Front light: | CONTEC "Dlux 80 E+" 80 Lux |
| Tail light: | CONTEC „TL-335 E-Stop“, mit Stoplicht |
| Frame Lock: | CONTEC "Powerloc M AZ" |
| Kickstand: | URSUS "King2", für Victoria Hinterbau, 40 mm, verstellbar |
| Pedals: | UNION "SP-828", Alu, Antislip |
Technical data
| Category: | trekking bike |
| E-bike: | yes |
| Bosch Smart System: | yes |
| Drive system: | BOSCH Performance Line |
| Drive version: | middle motor |
| Battery capacity: | 625 Wh |
| Support: | till 25km/h |
| Sex: | gents |
| Frame shape: | diamond |
| Frame size: | S |
| Frame height: | 50 cm |
| Wheel size: | 28" |
| Shifting type: | hub gear |
| Gears: | 5-speed |
| Circuit brand: | Shimano |
| Shifting model: | Nexus |
| Brake system: | hydraulic disc brake |
| Travel: | 63 mm |
| Features: | suspension fork, suspensed seat post, frame lock, system carrier, chain guard, electronic sliding aid, fender |
| Zulässiges Systemgewicht: | 140 kg |
| Material: | aluminium |
| Colour: | black |
| Colour designation: | airstream silver |
| Weight: | 29,80 kg |
| EAN | 4251971165939 |
Geometry data "Victoria TRESALO 15 diamond (2025)"
| Seat tube: | 500 mm |
| Toptube: | 584 mm |
| Steering tube angle: | 70° |
| Seat angle: | 73° |
| Kettenstrebe: | 490 mm |
| Steering tube: | 155 mm |
| Reach: | 390 mm |
| Stack: | 634 mm |
