"TRESALO 5 diamond "
Upright and comfortable - that's the best way to describe the TRESALO 5. The Bosch "PowerPack 545", which is concealed by a cover, finds its rightful place in the down tube and can either be easily removed upwards for charging or charged directly in the bike.
The heart of the e-bike is still the Bosch "Active Line Plus" mid-motor, which generally provides quiet and good-natured support with a torque of 50 Nm. Its four modes can be selected via the "Intuvia" Display. The low-maintenance "Nexus" hub gears with coaster brake provide support with their seven gears and can influence the range of the e-bike when used efficiently.
Reliable brakes are the be-all and end-all when biking - especially at higher speeds, which can be achieved with the TRESALO 5. This is where the hydraulic "HS22" Rim Brakes from Magura come into play. Their braking force can be precisely controlled using the ergonomic levers.
The suspension Fork and Seatposts provide the usual high Victoria comfort standard, as do the Ergotec Handlebars, which ensure a more upright riding position. The wide tires provide damping when riding over cobblestones or paved forest paths.
When it gets later in the evening, the Contec Front Light with 50 lux illuminates the way home brightly. The rear light with stop light function even provides extra safety for cyclists following behind. All standard bags and baskets can be easily clicked onto the MIK system carrier using the appropriate adapter.
The heart of the e-bike is still the Bosch "Active Line Plus" mid-motor, which generally provides quiet and good-natured support with a torque of 50 Nm. Its four modes can be selected via the "Intuvia" Display. The low-maintenance "Nexus" hub gears with coaster brake provide support with their seven gears and can influence the range of the e-bike when used efficiently.
Reliable brakes are the be-all and end-all when biking - especially at higher speeds, which can be achieved with the TRESALO 5. This is where the hydraulic "HS22" Rim Brakes from Magura come into play. Their braking force can be precisely controlled using the ergonomic levers.
The suspension Fork and Seatposts provide the usual high Victoria comfort standard, as do the Ergotec Handlebars, which ensure a more upright riding position. The wide tires provide damping when riding over cobblestones or paved forest paths.
When it gets later in the evening, the Contec Front Light with 50 lux illuminates the way home brightly. The rear light with stop light function even provides extra safety for cyclists following behind. All standard bags and baskets can be easily clicked onto the MIK system carrier using the appropriate adapter.
Specifications "Victoria TRESALO 5 diamond (2025)"
| Frame: | Alu 6061 |
| Dropout: | Slider Dropout |
| Fork: | SUNTOUR "SF14 CR-85 E25", einstellbar, 50mm Travel, Pivot |
| Crank arm: | Miranda "PSI" |
| Chain ring / belt ring: | MIRANDA, 38T |
| Bottom Bracket: | BOSCH |
| Brakes: | MAGURA "HS22" |
| Brake lever: | MAGURA "HS22" |
| Shifting lever: | SHIMANO "Nexus", 7-Gg. |
| Cassette / belt sprocket: | SHIMANO, 20 Z. |
| Chain / belt: | KMC "Z1eHX Narrow EPT" |
| Drive unit: | BOSCH Mittelmotor Gen.3 "Active Line PLUS", 36 V, 250 W |
| Battery: | BOSCH "Powerpack 500", Lithium-Ionen mit BMS, 500 Wh |
| Charger: | BOSCH 4 Ah |
| Display: | BOSCH, "Intuvia " 4-Stufen, Remote Control, Schiebehilfe |
| Sensor: | Tretkraftmessung im Motor + Geschwindigkeitssensor |
| Rims: | MACH "670" |
| Spokes: | 2,0 mm, Niro |
| Front hub: | SHIMANO "HB-TX500", 36 L., QR |
| Rear hub: | SHIMANO "Nexus" 7-Gg. RBN |
| Front tires: | MAXXIS "Metropass", 50-622, Reflex |
| Rear tires: | MAXXIS "Metropass", 50-622, Reflex |
| Handle bar: | ERGOTEC "Riser Bar 50", 720 mm, Ø 31,8 mm, schwarz |
| Stem: | ERGOTEC "Sepia 50", Ø31,8 mm, verstellbar, schwarz, 90mm |
| Grips: | CONTEC "Tour Wing" |
| Saddle: | SELLE ROYAL "ESSENZA" Italy, Relaxed |
| Seat post: | ERGOTEC Patent "SP10", gefedert, Ø 27,2 mm, Alu |
| Chain guard: | HESLING "Move" Bosch Gen.3 |
| Mud Guards: | CURANA "Apollo", 60mm, schwarz matt, Spoiler |
| Carrier: | MIK-ALU-GEPÄCKTRÄGER "TA7611A" MIK-System |
| Front light: | CONTEC "Dlux 50 E+" 50 Lux |
| Tail light: | CONTEC „TL-335 E-Stop“, mit Stoplicht |
| Frame Lock: | CONTEC "Powerloc M AZ" |
| Kickstand: | URSUS "King2", für Victoria Hinterbau, 40 mm, verstellbar |
| Pedals: | UNION "SP-828", Alu, Antislip |
Technical data
| Category: | trekking bike |
| E-bike: | yes |
| Bosch Smart System: | no |
| Drive system: | BOSCH Active Line Plus |
| Drive version: | middle motor |
| Battery capacity: | 500 Wh |
| Support: | till 25km/h |
| Sex: | gents |
| Frame shape: | diamond |
| Frame size: | S |
| Frame height: | 48 cm |
| Wheel size: | 28" |
| Shifting type: | hub gear |
| Gears: | 7-speed |
| Circuit brand: | Shimano |
| Shifting model: | Nexus |
| Brake system: | hydraulic rim brake, coaster brake |
| Travel: | 50 mm |
| Features: | suspension fork, suspensed seat post, frame lock, system carrier, chain guard, electronic sliding aid, fender |
| Zulässiges Systemgewicht: | 140 kg |
| Material: | aluminium |
| Colour: | grey |
| Colour designation: | cosmos anthracite matt |
| Weight: | 27,40 kg |
| EAN | 4251971166769 |
Geometry data "Victoria TRESALO 5 diamond (2025)"
| Seat tube: | 480 mm |
