"Avyon 4 wave "
The "AVYON 4", which, like its siblings, is equipped with the "Performance CX" engine, is our entry into the world of Victoria Overlander with Bosch "Smart System" drives. It gets its energy from the "PowerTube 625".
The new, clearly structured "Kiox 300" color display is not only easy to read during the day and in the dark, it is also very easy to operate via the LED remote unit on the left-hand side of the Handlebar. The various speed levels can also be customized using the free eFlow app in Victoria design. Depending on requirements, they provide more assistance than the factory setting or consume less power.
On the suspension side, the "AVYON 4" is also equipped with an air suspension fork and sturdy Thru Axles at the front and rear, which can be experienced directly from the first few meters in the form of a very safe riding experience. It comes to a safe stop with 203/180 mm hydraulic disc brakes, and even with a sturdy four-piston brake system at the front.
The new Shimano "Cues" 9-speed derailleur changes gears.
The new "eRuban" SUV all-round tires from Continental help to increase tires thanks to the energy-saving tread. The higher shoulder lugs provide the necessary grip on damp meadows and loose ground.
The "AVYON 4" is available in two Frame versions and paints. As with all new Victoria developments, the Bosch PowerTube batteries integrated in the down tube can be removed from the top, but can of course also be charged directly in the bike when installed.
The new, clearly structured "Kiox 300" color display is not only easy to read during the day and in the dark, it is also very easy to operate via the LED remote unit on the left-hand side of the Handlebar. The various speed levels can also be customized using the free eFlow app in Victoria design. Depending on requirements, they provide more assistance than the factory setting or consume less power.
On the suspension side, the "AVYON 4" is also equipped with an air suspension fork and sturdy Thru Axles at the front and rear, which can be experienced directly from the first few meters in the form of a very safe riding experience. It comes to a safe stop with 203/180 mm hydraulic disc brakes, and even with a sturdy four-piston brake system at the front.
The new Shimano "Cues" 9-speed derailleur changes gears.
The new "eRuban" SUV all-round tires from Continental help to increase tires thanks to the energy-saving tread. The higher shoulder lugs provide the necessary grip on damp meadows and loose ground.
The "AVYON 4" is available in two Frame versions and paints. As with all new Victoria developments, the Bosch PowerTube batteries integrated in the down tube can be removed from the top, but can of course also be charged directly in the bike when installed.
Specifications "Victoria Avyon 4 wave (2025)"
| Frame: | Bosch-Intube-SUV-Frame, Aluminium 6061 |
| Fork: | SUNTOUR "SF21-MOBIE34 AIR", einstellbar, Lockout, 100mm |
| Crank set: | FSA "W0147 + WB488", megatooth |
| Crank arm: | FSA "CK-745", Gen.4 |
| Chain ring / belt ring: | FSA, 38T, megatooth |
| Bottom Bracket: | BOSCH |
| Brakes: | SHIMANO "BR-MT200" |
| Brake lever: | SHIMANO "BR-MT201" |
| Front rotor: | SHIMANO "SM-RT30", 203mm, Center-Lock |
| Rear rotor: | SHIMANO "SM-RT30", 180mm, Center-Lock |
| Shifting lever: | SHIMANO "Cues" |
| Rear derailleur: | SHIMANO "Cues" |
| Cassette / belt sprocket: | SHIMANO "Cues" |
| Chain / belt: | SHIMANO "CN-LG500" |
| Drive unit: | BOSCH "Performance CX", 36 V, 250 W |
| Battery: | BOSCH "PowerTube 625", Lithium-Ionen mit BMS, 625 Wh |
| Charger: | BOSCH 2 Ah |
| Remote: | BOSCH, "BRC3600" LED Remote |
| Display: | BOSCH, "Kiox 300" 4-Stufen, Remote Control, Schiebehilfe |
| Sensor: | Tretkraftmessung im Motor + Geschwindigkeitssensor |
| Rims: | MACH 1 "MAXX" |
| Spokes: | 2,0 mm, Niro, black |
| Front hub: | SHIMANO "HB-MT400", OLD 100 mm, 15mm, Disc, Center Lock |
| Rear hub: | SHIMANO "FH-MT400-B ", Disc |
| Front tires: | MAXXIS "Rekon", 61-584, Reflex |
| Rear tires: | MAXXIS "Rekon", 61-584, Reflex |
| Handle bar: | CONTEC "Mito 60", Breite 680 mm, Rise 15 mm, 15° Backsweep |
| Stem: | CONTEC "Lida", 31,8 mm, 90 mm, Ahead, verstellbar, schwarz |
| Grips: | CONTEC "G-Link MTB Smol Wing" |
| Saddle: | SELLE ROYAL "Explora" Italy, Moderate Female |
| Seat post: | ERGOTEC Patent "Viper", Ø 31,6 mm, 10mm Setback, Alu, black |
| Chain guard: | CURANA "Chainguard" |
| Mud Guards: | CURANA "Apollo", 70mm, schwarz matt, Spoiler |
| Carrier: | MIK-ALU-GEPÄCKTRÄGER "TA7652A" MIK-System |
| Front light: | CONTEC "Dlux 50 E+" 50 Lux |
| Tail light: | CONTEC „TL-335 E-Stop“, mit Stoplicht |
| Frame Lock: | CONTEC "Powerloc XL AZ" |
| Kickstand: | URSUS "King2", für Victoria Hinterbau, 40 mm, verstellbar |
| Pedals: | VP "VP-531E", Alu, |
Technical data
| Category: | SUV |
| E-bike: | yes |
| Bosch Smart System: | yes |
| Drive system: | BOSCH Performance Line CX |
| Drive version: | middle motor |
| Battery capacity: | 625 Wh |
| Support: | till 25km/h |
| Sex: | ladies |
| Frame shape: | wave |
| Frame size: | S |
| Frame height: | 46 cm |
| Wheel size: | 27,5" |
| Drive: | chain drive |
| Shifting type: | derailleur |
| Gears: | 9-speed |
| Transmission: | 1x 9-fach |
| Circuit brand: | Shimano |
| Shifting model: | Cues |
| Brake system: | hydraulic disc brake |
| Travel: | 100 mm |
| Features: | suspension fork, system carrier, chain guard, electronic sliding aid, fender |
| Zulässiges Systemgewicht: | 140 kg |
| Material: | aluminium |
| Colour: | black |
| Colour designation: | night black matt |
| Weight: | 28,90 kg |
| EAN | 4251971170575 |
Geometry data "Victoria Avyon 4 wave (2025)"
| Seat tube: | 460 mm |
| Toptube: | 599 mm |
| Steering tube angle: | 69° |
| Seat angle: | 73° |
| Kettenstrebe: | 467 mm |
| Steering tube: | 150 mm |
| Reach: | 400 mm |
| Stack: | 650 mm |
| Standover height: | 420 mm |
| Wheel distance: | 1.137 mm |
