Avyon 10 diamond
4,999.00€ *
Your configuration changes
4,999.00€ *
| Frame: | Bosch-Intube-Elektro-Trekking-Frame, Aluminium |
| Dropout: | UDH |
| Fork: | ROCKSHOX "Recon RL" 100 mm, 27,5" |
| Headset: | FSA "55R" |
| Crank arm: | FSA 170 mm, ISIS |
| Chain ring / belt ring: | FSA 42 T. |
| Bottom Bracket: | BOSCH |
| Bremse V.R.: | SHIMANO "BL-MT4100(L)/BR-MT420(F)" SM-MA-F180, Resin Pad |
| Bremse H.R.: | SHIMANO "BL-M4100-BR-MT420(R)" SM-MA-F180P/P2, Resin Pad |
| Front rotor: | SHIMANO "SM-RT30", 203 mm, CenterLock |
| Rear rotor: | SHIMANO "SM-RT30", 180 mm CenterLock |
| Shifting lever: | SHIMANO "Deore XT SL-M8130", LINKGLIDE, 11-fach |
| Rear derailleur: | SHIMANO "Deore XT RD-M8130", LINKGLIDE, langer Käfig, 11-fach |
| Cassette / belt sprocket: | SHIMANO "Deore XT CS-M8000", 11-fach, 11-46 Zähne |
| Chain / belt: | SHIMANO "CN-LG500" |
| Drive unit: | BOSCH "Performance Line CX" BES3 |
| Battery: | BOSCH "PowerTube 800" 800 Wh |
| Charger: | BOSCH 4 A, BES3 |
| Remote: | BOSCH "Mini Remote" 22,2 mm |
| System interface: | BOSCH "BRC3100" |
| Display: | BOSCH "Kiox 500" |
| Sensor: | Tretkraftmessung im Motor + Geschwindigkeitssensor |
| Rims: | RODI "BlackRock 25" 27,5", 25-584, 36 Loch, Schwarz |
| Spokes: | 2,0 mm, Niro, schwarz |
| Front hub: | SHIMANO "HB-M8110-B" Deore XT, Center Lock, 15x110mm, 36H |
| Rear hub: | SHIMANO "FH-M8010" Deore XT, 8/9/10/11-Fach, Center Lock, 36H, 12x148mm |
| Front tires: | MAXXIS "Rekon", 61-584, Reflex |
| Rear tires: | MAXXIS "Rekon", 61-584, Reflex |
| Handle bar: | SATORI "WIEN", 31,8mm, 680mm, Rise 20°, Backsweep 15° |
| Stem: | SATORI "Hatchback", 31,8 mm, 90 mm |
| Grips: | HERRMANS "Nucore Grip Town Peak" |
| Saddle: | SELLE ROYAL "Explora", Moderate |
| Seat post: | LIMOTEC "B3", 31,6 mm, Dropper-Post, Travel 40+60 mm, 345 mm, Schwarz |
| Chain guard: | CURANA "C-Lite Chainguard" M+, Avyon, Schwarz |
| Schutzblech V.R.: | CURANA "Orbit", 65 mm, schwarz matt |
| Schutzblech H.R.: | CURANA "Orbit", 65 mm, schwarz matt, Nano COB |
| Carrier: | MIK HD |
| Front light: | BUSCH & MÜLLER "Lumotec IQ-XS highbeam", 100 Lux |
| Tail light: | Büchel "Nano COB", integriert im Schutzblech |
| Frame Lock: | ABUS "4750" XL |
| Kickstand: | URSUS "R97 IC invisible Connect" |
| Pedals: | MARWI "SP-828" Victoria Logo, Schwarz |
| Others: | HTM 2.0 Aufnahme |
| Category: | SUV |
| E-bike: | yes |
| Bosch Smart System: | yes |
| Drive system: | BOSCH Performance Line CX |
| Drive version: | middle motor |
| Battery capacity: | 800 Wh |
| Support: | till 25km/h |
| Sex: | gents |
| Frame shape: | diamond |
| Frame size: | S |
| Frame height: | 48 cm |
| Wheel size: | 27,5" |
| Drive: | chain drive |
| Shifting type: | derailleur |
| Gears: | 11-speed |
| Transmission: | 1x 11-fach |
| Circuit brand: | Shimano |
| Shifting model: | Deore XT |
| Brake system: | hydraulic disc brake |
| Travel: | 100 mm |
| Features: | suspension fork, system carrier, chain guard, electronic sliding aid, fender |
| Zulässiges Systemgewicht: | 140 kg |
| Material: | aluminium |
| Colour: | blue |
| Colour designation: | lapis blue matt |
| Weight: | 28,70 kg |
| EAN | 4251971179615 |
| Seat tube: | 480 mm |
| Toptube: | 615 mm |
| Steering tube angle: | 69° |
| Stem length: | 90 mm |
| Seat angle: | 73° |
| Kettenstrebe: | 459 mm |
| Steering tube: | 145 mm |
| Reach: | 410 mm |
| Stack: | 670 mm |
